起源の場所:
中国
ブランド名:
OEM
モデル番号:
ML1220 リチウム電池 18mah 3V バッテリー
3.0Volt 18mah Cmos Battery ML1220 lithium rechargeable battery ML1220 cion cell battery factory
ML1220 Rechargeable Lithium Battery 3V CoinCell battery MI1220 lithium battery MI1220 3V Battery ML1220 Recharageable limno2 battery ML1220 3Volt battery ML1220 18mah Battery ML1220 Coin limno2 battery 12.5mm 3 V Lithium Battery Rechargeable button battery ML1200 Secondary 18mAh rechargeable lithium coin type batteries Ml1220 small rechargeable cion battery ML1220 battery is commonly used in electronic devices such as notebook and laptop computers, PDAs, tablet PCs, digital cameras and more
ML1220 3V Rechargeable cion size battery ML1220 CMOS RTC BIOS Back Up Battery 3.0 volt Lithium-aluminum button battery ML1220 3V Rechargeable lithium battery 3V 18mah Manganese Lithium Coin Batteries Manufacturer luS battery
Battery type Li-mno2 cion type rechargeable battery
Battery seires button type rechargeable battery
Voltage 3.0 vdc
Capacity 17mah 18mah small size rechargeable battery
| CLASSIFICATION | MANGANESE DIOXIDE LITHIUM RECHARGEABLE BATTERY |
| BATTERY SYSTEM | COIN TYPE MANGANESE DIOXIDE LITHIUM BATTERY |
| BATTERY TYPE | ML1220 |
| NOMINAL VOLTAGE | 3.0V |
| NOMINAL CAPACITY | 18mAh (ON CONTINUOUS DISCHARGE UNDER 30kΩ load to 2.0V end-point) |
| STANDARD DISCHARGE CURRENT | 0.1mA |
| MASS | APPROX. 0.85g |
| SIZE | Φ12.5(+0/-0.3)mm 2.0(+0/-0.2)mm |
| USABLE TEMPERATURE RANGE | -20ºC~+70ºC |
| STORAGE TEMPERATURE RANGE | 0ºC~30ºC |
| STORAGE HUMIDITY RANGE | 35%~75% |
ML1220 lithium battery 3VDC rechargeable limno2 battery ML1220 batteris
This small rechargeable ML1220 battery is commonly used in
electronic devices
such as notebook and laptop computers, PDAs, tablet PCs, digital cameras
and communications equipment.
It is commonly used as a backup clock battery in many timer equipped home electronics
devices.
|
Mode |
Voltage(V) | Capacity(mAh) | Dimension(mm) | Weight(g) | Chargeable or Non |
| CR2032 | 3 | 220 | 20.0*3.2 | 3 | Non |
| CR2032 | 3 | 240 | 20.0*3.2 | 3 | Non |
| CR1220 | 3 | 35 | 12.5*2.0 | 0.8 | Non |
| CR1225 | 3 | 50 | 12.5*2.5 | 0.9 | Non |
| CR1616 | 3 | 50 | 16.0*1.6 | 1.1 | Non |
| CR1620 | 3 | 70 | 16.0*2.0 | 1.3 | Non |
| CR1632 | 3 | 120 | 16.0*3.2 | 1.8 | Non |
| CR2016 | 3 | 83 | 20.0*1.6 | 1.7 | Non |
| CR2025 | 3 | 150 | 20.0*2.5 | 2.5 | Non |
| CR2450 | 3 | 600 | 24.5*5.0 | 6.2 | Non |
| CR3032 | 3 | 550 | 30.0*3.2 | 7 | Non |
| ML1220 | 3 | 17 | 12.5*2.0 | 0.8 | Yes |
| Model | Nominal Voltage (V) | Nominal Capacity (mAh) | Max. Discharge Current (mA) | Resistance (mΩ) | Diameter (mm) | Height (mm) | Weight Approx (g) |
| LIR1025 | 3.6 | 6±2 | 1C | 10.0 -0.15 | 2.5 +0.15 | 1.1±0.2 | |
| LIR1220 | 3.6 | 8±2 | 1C | 12.5 -0.2 | 2.0 +0.35 | 0.8±0.3 | |
| LIR1254 | 3.6 | 65±5 | 1C | ≤600 | 12.0 -0.2 | 5.4 +0.2 | 1.8±0.2 |
| LIR1620 | 3.6 | 16±2 | 1C | ≤2000 | 16.0 -0.2 | 2.0 +0.35 | 1.2±0.3 |
| LIR1632 | 3.6 | 25±2 | 1C | ≤2000 | 16.0 -0.2 | 3.2 +0.35 | 1.7±0.3 |
| LIR1654 | 3.6 | 120±5 | 1C | ≤600 | 16.0 -0.2 | 5.4 +0.2 | 2.4±0.2 |
| LIR2016 | 3.6 | 18±2 | 2C | ≤2000 | 20.0 -0.2 | 1.6 +0.35 | 1.7±0.3 |
| LIR2025 | 3.6 | 25±5 | 2C | ≤2000 | 20.0 -0.2 | 2.5 +0.25 | 2.3±0.3 |
| LIR2032 | 3.6 | 40±5 | 2C | ≤600 | 20.0 -0.2 | 3.2 +0.35 | 2.8±0.3 |
| LIR2050 | 3.6 | 80±5 | 2C | ≤600 | 20.0 -0.2 | 5.0 +0.2 | 3.8±0.2 |
| LIR2430 | 3.6 | 60±5 | 2C | ≤500 | 24.5 -0.2 | 3.0 +0.35 | 3.8±0.3 |
| LIR2450 | 3.6 | 120±10 | 2C | ≤450 | 24.5 -0.2 | 5.0 +0.35 | 5.0±0.3 |
| LIR2477 | 3.6 | 180±10 | 2C | ≤400 | 24.5 -0.2 | 7.7 +0.3 | 7.0±0.3 |
LUS battery welcome any lithium battery 3V coin size battery 3.0V rechargeable battery customization
